Keithley 2600a series User Manual

2600AS-901-01 Rev. B / September 2008 Return to Section Topics 2-3
Series 2600A System SourceMeter® Instruments Reference Manual Section 2: DUT Test Connections
Figure 2-1
2602A/2612A input/output connectors
Figure 2-2
Model 2636A input/output connectors
S
HI
CHANNEL B
GGGG S
LO
HI LO
S
HI
CHANNEL A
G
GGG
S
LO
HI
LO
Channel B Channel A
HI = Input/Output HI
S HI = Sense HI
G = Guard
S LO = Sense LO
LO = Input/Output LO
Captive screw (2 per terminal block)
Each terminal block uses two captive
screws to secure it to the rear panel.
GND
(outer shield)
LO
(inner shield)
GUARD
(inner shield)
Sense LO
(center conductor)
HI
(center conductor)
Sense HI
(center conductor)
Sense HI
(center conductor)
HI
(center conductor)
Sense LO
(center conductor)
GND
(outer shield)
GUARD
(inner shield)
LO
(inner shield)
Channel A
Channel B

Keithley 2600a series Specifications

General

Category	Source Measure Unit (SMU)
Model	2600A Series
Type	Precision SourceMeter
Voltage Range	±200V
Current Range	±10fA to ±10A (depending on model)
DC Current	±10A
Pulse Current	±100A
Maximum Power	20W to 200W (depending on model)
Power per Channel	20W
Accuracy	0.012% basic
Interface	GPIB, USB, Ethernet
Power Supply	100V to 240V, 50Hz to 60Hz
Weight (1-channel)	4.5kg
Channels	1 or 2
Dimensions (1-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
Dimensions (2-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
