1-8 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 1: Getting Started Series 2600A System SourceMeter® Instruments Reference Manual
Bottom row
LOAD Loads factory or user-defined scripts for execution.
RUN Runs the last selected factory or user-defined scripts.
STORE Stores readings, source values, and timestamp values in one of two internal buffers
per channel for later recall.
RECALL Recalls stored readings, source values, and timestamp values from either of the two buffers.
TRIG Triggers readings.
MENU Accesses the main menu for saving and recalling setups, selecting a remote interface, line
frequency, self-tests, serial number, and beeper control.
EXIT Cancels selection and backs out of menu structure. Also used as a LOCAL key to take the
unit out of remote.
ENTER Accepts selection and moves to the next choice or exits the menu.
3. Range keys:
and Selects the next higher or lower source or measure range.
AUTO Enables or disables source or measure auto range.
4. Output control and LED status indicator:
OUTPUT ON/OFF Turns source output on or off.
LED indicator Turns on when output is on.
5. Navigation Wheel, USB port, and cursor keys:
Use the CURSOR keys to move the cursor left or right. Once you select the desired source or compliance
value, push the navigation wheel to edit the value. You can use the navigation wheel to enable or disable
the edit mode.
Use the CURSOR keys or navigation wheel to navigate through menu items. To view a menu value, use
the CURSOR keys for cursor control and then rotate the navigation wheel to change the value. Push the
navigation wheel to open the submenu items or to select a menu option or a value.
Use the USB port to connect with a USB flash drive. The USB flash drive stores reading buffer data,
scripts, and user setup options.
6. Display indicators (not shown):
EDIT Unit is in the source editing mode
ERR Questionable reading or invalid cal step
REM Unit in remote mode
TALK Unit is addressed to talk
LSTN Unit is addressed to listen
SRQ Service request
REL Relative mode enabled
FILT Digital filter is enabled
AUTO Auto source or measure range is selected
ARM Unit is armed and ready to run
* (asterisk) Readings are being stored in the buffer
