Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
smuX.trigger.source.stimulus
X = SMU channel (a or b)
Attribute Selects the event which causes the source event detector to enter the detected state.
Default 0
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage eventid = smuX.trigger.source.stimulus -- Reads source action trigger.
smuX.trigger.source.stimulus = eventid -- Writes source action trigger.
eventid Event that triggers the source action.
Remarks • Set this attribute to zero to bypass waiting for an event.
• Set this attribute to the event ID of any trigger event generator to wait for that event.
• The SMU will automatically clear all event detectors when the smuX.trigger.initiate
function is executed. This function should be called after the sweep is initiated.
Also see smuX.trigger.initiate
smuX.trigger.SOURCE_COMPLETE_EVENT_ID X = SMU channel (a or b)
Attribute The source complete event number.
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage event_id = smuX.trigger.SOURCE_COMPLETE_EVENT_ID
event_id Source action complete event number.
Remarks • Set the stimulus of any trigger event detector to the value of this constant to have it respond to
source complete events from this SMU.
smuX.trigger.SWEEP_COMPLETE_EVENT_ID X = SMU channel (a or b)
Attribute The sweep complete event number.
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage event_id = smuX.trigger.SWEEP_COMPLETE_EVENT_ID
event_id Sweep complete event number.
Remarks • Set the stimulus of any trigger event detector to the value of this constant to have it respond to
sweep complete events from this SMU.
smuX.trigger.SWEEPING_EVENT_ID X = SMU channel (a or b)
Attribute The sweeping event number.
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage event_id = smuX.trigger.SWEEPING_EVENT_ID
event_id Sweeping event number.
Remarks • Set the stimulus of any trigger event detector to the value of this constant to have it respond to
sweeping events from this SMU.

Keithley 2600a series Specifications

General

Category	Source Measure Unit (SMU)
Model	2600A Series
Type	Precision SourceMeter
Voltage Range	±200V
Current Range	±10fA to ±10A (depending on model)
DC Current	±10A
Pulse Current	±100A
Maximum Power	20W to 200W (depending on model)
Power per Channel	20W
Accuracy	0.012% basic
Interface	GPIB, USB, Ethernet
Power Supply	100V to 240V, 50Hz to 60Hz
Weight (1-channel)	4.5kg
Channels	1 or 2
Dimensions (1-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
Dimensions (2-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
