Keithley 2600a series User Manual

In this section:
Topic Page
Overview............................................................................................. 4-2
Compliance limit ................................................................................ 4-2
Maximum compliance.................................................................... 4-2
Compliance principles ................................................................... 4-2
Overheating protection ..................................................................... 4-3
Power equations to avoid overheating .......................................... 4-3
Operating boundaries ....................................................................... 4-6
Source or sink ............................................................................... 4-6
Continuous power operating boundaries....................................... 4-6
I-Source operating boundaries ...................................................... 4-7
V-Source operating boundaries..................................................... 4-11
Source I measure I, source V measure V ..................................... 4-15
Basic circuit configurations ............................................................. 4-15
Source I......................................................................................... 4-15
Source V........................................................................................ 4-16
Measure only (V or I)..................................................................... 4-16
Contact check................................................................................ 4-17
Guard .................................................................................................. 4-18
Guard overview ............................................................................. 4-18
Guard connections ........................................................................ 4-19
Settling time considerations............................................................. 4-20
Measurement settling time considerations .................................... 4-20
Reduction in gain-bandwidth ......................................................... 4-22
Section 4
Source-Measure Concepts

Keithley 2600a series Specifications

General

Category	Source Measure Unit (SMU)
Model	2600A Series
Type	Precision SourceMeter
Voltage Range	±200V
Current Range	±10fA to ±10A (depending on model)
DC Current	±10A
Pulse Current	±100A
Maximum Power	20W to 200W (depending on model)
Power per Channel	20W
Accuracy	0.012% basic
Interface	GPIB, USB, Ethernet
Power Supply	100V to 240V, 50Hz to 60Hz
Weight (1-channel)	4.5kg
Channels	1 or 2
Dimensions (1-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
Dimensions (2-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
