D3-14 24VDC Electrical System Components D03026
TABLE I. CIRCUIT BREAKERS
AMPS DEVICE(S) PROTECTED LOCATION
CB13 15 Turn Signal & Clearance Lights RB1, Control Cabinet
CB14 15 Flashing Lights RB1, Control Cabinet
CB15 15 RD1, RD2, & Tail Lights RB1, Control Cabinet
CB16 15 Dynamic Retard Lights RB3, Control Cabinet
CB17 15 Manual Back-up Lights RB3, Control Cabinet
CB18 15 Stop Lights RB3, Control Cabinet
CB19 15 Back-up Horn RB3, Control Cabinet
CB20 5 Parking Brake Failure Relay RB4, Control Cabinet
CB21 15
Fluid Components Cabinet Service Lights, Rear Axle Service Light,
Horn Solenoid, Steering Accumulator Bleed Down Solenoid, Horn
RB4, Control Cabinet
CB22 5 DDEC Master ECM Control Power (DDEC Engine Only) RB4, Control Cabinet
CB23 15 Low Beam Headlight, L.H. RB5, Control Cabinet
CB24 15 Low Beam Headlight, R.H. RB5, Control Cabinet
CB25 15 High Beam Headlight, L.H. RB5, Control Cabinet
CB26 15 High Beam Headlight, R.H. RB5, Control Cabinet
CB27 15 Clearance Light Relay, Panel Lights, High Beam Indicator RB5, Control Cabinet
CB28 15 Payload Meter RB2, Control Cabinet
CB29 5 Payload Meter RB2, Control Cabinet
CB30 15 Ladder, Engine Service & (Optional) Fog Lights, Hourmeter Operator Cab, Power Distribution Module
CB31 15 Heater/AC Circuits Operator Cab, Power Distribution Module
CB32 15
Warning Lights, A.I.D. Module, Voltmeter, Turn Signal Relays & Indi-
cator Lights
Operator Cab, Power Distribution Module
CB33 15 Hoist Solenoid Operator Cab, Power Distribution Module
CB34 10 Air Dryer Heater Operator Cab, Power Distribution Module
CB35 10 Lincoln Lube Solenoid Operator Cab, Power Distribution Module
CB36 10 Cigar Lighter Operator Cab, Power Distribution Module
CB37 10 Windshield Washer & Wiper Operator Cab, Power Distribution Module
CB38 5 Fuel gauge, Engine Temperature Gauge Operator Cab, Power Distribution Module
CB39 5 Radiator Pressure Solenoid / Auto Lubrication Operator Cab, Power Distribution Module
CB40 5 12VDC Accessory Receptacle (DDEC Engine Only) Operator Cab, Power Distribution Module
CB40A 5 12VDC Accessory Receptacle Operator Cab, Power Distribution Module
CB40B 10 Radio/Cassette Player Operator Cab, Power Distribution Module
CB41A 15 Cab Door Window, L.H. Operator Cab, Power Distribution Module
CB41B 15 Cab Door Window, R.H. Operator Cab, Power Distribution Module
CB42 15 Air Seat Operator Cab, Power Distribution Module
CB43 10 Starter Solenoid, Oil Pressure Latch Relay Operator Cab, Power Distribution Module
CB44 20 DDR Connections, Coolant Level Module (DDEC Engine Only) Battery Equalizer Box
CB45 20 DDEC Main ECM 12VDC Power (DDEC Engine Only) Battery Equalizer Box
CB46 20 DDEC Main ECM 12VDC Power (DDEC Engine Only) Battery Equalizer Box
CB47 20 DDEC Receiver ECM 12VDC Power (DDEC Engine Only) Battery Equalizer Box
CB48 20 DDEC Receiver ECM 12VDC Power (DDEC Engine Only) Battery Equalizer Box
CB50 20 Communications Radio Operator Cab, Power Distribution Module
CB51 20 Dispatch Radio Operator Cab, Power Distribution Module
CB52 5 MM Dispatch Operator Cab, Power Distribution Module
CB53 25 MM Dispatch Operator Cab, Power Distribution Module
