E2-18 Electrical Propulsion Components 2/02 E02016
TABLE II. 2-DIGIT DISPLAY PANEL SUBCODES
PRIMARY
CODE
No.
SUBCODE
No.
TERM DESCRIPTION
ANALOG OUTPUT
30:
54 AF_CURR_REF D/A Commanded to output >10 volts for over 0.05 seconds
55 MF_CURR_REF D/A Commanded to output >10 volts for over 0.05 seconds
56 BRKBLV D/A Commanded to output >10 volts for over 0.05 seconds
57 ENGRPMCMD D/A Commanded to output >10 volts for over 0.05 seconds
61 SIG1 D/A Commanded to output >10 volts for over 0.05 seconds
62 SIG2 D/A Commanded to output >10 volts for over 0.05 seconds
63 SIG3 D/A Commanded to output >10 volts for over 0.05 seconds
64 SIG4 D/A Commanded to output >10 volts for over 0.05 seconds
65 SIG5 D/A Commanded to output >10 volts for over 0.05 seconds
ANALOG INPUT
32:
18 GND A/D Scaled output > 16 or <-16 for 0.02 seconds
19 GAINCHK A/D Scaled output > 1675 or <-1600 for 0.02 seconds
20 GROUND_FAULT A/D Scaled output > 523 or <-523 for 0.3 seconds
21 M1_AMPS A/D Scaled output > 3500 or <-3500 for 1.0 second
22 M2_AMPS A/D Scaled output > 3500 or <-3500 for 1.0 second
23 MF_AMPS A/D Scaled output > 1500 or <-1500 for 1.0 second
24 ALT_F_AMPS A/D Scaled output > 800 or <-30 for 0.5 seconds
25 ENGHPCUT A/D Scaled output > 4.95 or <-4.95 for 1.0 second
26 SRS A/D Scaled output > 23 or <-1 for 1.0 second
27 RPINHI A/D Scaled output > 23 or <-1 for 1.0 second
28 ALTFVOLT A/D Scaled output > 1000 or <-25 for 1.0 second
29 ALT_OUT_VOLT A/D Scaled output > 2250 or <-50 for 1.0 second
30 M2_VOLTS A/D Scaled output > 1200 or <-1200 for 1.0 second
31 APINHI A/D Scaled output > 25 or <-1.0 for 1.0 second
32 SVBE A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
33 TMFSE A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
34 ATOC A/D Scaled output > 2400 or <-50 for 1.0 second
35 MTOC A/D Scaled output > 2400 or <-50 for 1.0 second
36 M1TS A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
37 M2TS A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
38 TAFSE A/D Scaled output > 5.0 or < 0 for 1.0 second
39 PAYLOAD A/D Scaled output > 10.0 or < 0 for 1.0 second
40 COOLT A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
41 COOLP A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
42 CRANKP A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
43 OILP A/D Scaled output > 5.2 or <-5.2 for 10.0 seconds
