E2-54 Electrical Propulsion Components 2/02 E02016
TABLE IV. STATISTICAL DATA CODES - PROFILES
PAR
No.
DESCRIPTION COUNT CONDITIONS BUCKET No.
CURRENT
VALUE
(AMPS)
80
M1 Amps Propel
(In seconds)
This is a histogram of Motor #1 armature current in propulsion
mode.
. . . . Sample time is 1.0 second
. . . . The clock will start whenever propulsion mode is selected.
The histogram breaks the current spectrum into 17 buckets defined
at right, and displays the time spent in each bucket.
1 500 & below
2 501 to 750
3 751 to 850
4 851 to 950
5 951 to 1050
6 1051 to 1150
7 1151 to 1250
8 1251 to 1350
81
M2 Amps Propel
(In seconds)
This is a histogram of Motor #2 armature current in propulsion
mode.
. . . . Sample time is 1.0 second
. . . . The clock will start whenever propulsion mode is selected.
The histogram breaks the current spectrum into 17 buckets defined
at right, and displays the time spent in each bucket.
9 1351 to 1450
10 1451 to 1550
11 1551 to 1800
12 1801 to 2150
13 2151 to 2300
14 2301 to 2600
15 2601 to 2900
16 2901 to 3200
17 3201 & above
PAR
No.
DESCRIPTION COUNT CONDITIONS BUCKET No.
CURRENT
VALUE
(AMPS)
82
M1 Amps Retard
(in seconds)
This is a histogram of Motor #1 armature current in retard mode.
. . . . Sample time is 1.0 second
. . . . The clock will start whenever retard mode is selected.
The histogram breaks the current spectrum into 17 buckets defined
at right, and displays the time spent in each bucket.
1 200 & below
2 201 to 300
3 301 to 400
4 401 to 500
5 501 to 600
6 601 to 700
7 701 to 800
8 801 to 900
83
M2 Amps Retard
(in seconds)
This is a histogram of Motor #2 armature current in retard mode.
. . . . Sample time is 1.0 second
. . . . The clock will start whenever retard mode is selected.
The histogram breaks the current spectrum into 17 buckets defined
at right, and displays the time spent in each bucket.
9 901 to 1000
10 1001 to 1100
11 1101 to 1200
12 1201 to 1350
13 1351 to 1450
14 1451 to 1550
15 1551 to 1650
16 1651 to 1750
17 1751 & above
