TECHNICAL DATA 22
163
22.8 Shock absorber
Shock absorber article number 12.18.7T.63
Shock absorber WP XPLOR 5746
Low-speed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
High-speed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1 turn
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload 10 mm (0.39 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 57 … 63 N/mm (325 … 360 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 60 … 66 N/mm (343 … 377 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 63 … 69 N/mm (360 … 394 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 37 mm (1.46 in)
Riding sag 110 mm (4.33 in)
Fitted length 415 mm (16.34 in)
Shock absorber fluid ( p. 167) SAE 2.5
22.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, intake air temperature sen-
sor
EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, oil fill level sensor G 3/4 " 7 Nm (5.2 lbf ft)
Screw, oil pump holder on oil tank EJOTDELTA PT 45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, seat fixing EJOTEJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, emergency OFF switch (All
EXC models)
M4 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 5 Nm (3.7 lbf ft)
Spoke nipple, rear wheel M4.5 5 Nm (3.7 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, ground wire in tail section M5 5 Nm (3.7 lbf ft)
