1. Head light switch
Turn
the head-light-switch clockwise, and the following
lights are activated on the position of the head-light-
switch.
(1) Head light switch (A) Off
(B) On (low)
(C)
On (high)
[OFF] (A)
Head lights are OFF.
(B)
Head lights are dimmed as low beam.
(C)
Head lights are on as high beam.
2. Turn signal light switch
Turn signal with hazard light
• T
o
indicate a right turn with the hazard lights
already flashing (hazard on), turn the turn-signal-
light-switch clockwise.
• To indicate a left turn with the hazard lights already
flashing, turn the turn-signal-light-switch
counterclockwise.
When the left or right turn signal is activated in
combination with the hazard lights, the indicated turning
light will flash and the other will stay on.
Turn signal without hazard light
• To
indicate a right turn without hazard lights (hazard
off), turn the turn-signal-light-switch clockwise.
• To indicate a left turn without hazard lights, turn the
turn-signal-light-switch counterclockwise.
When the left or right turn signal is activated without the
hazard lights, the indicated turning light will flash and
the other will be on.
(1) Turn signal light switch
(2)
T
urn signal / hazard light in-
dicator
(A) Right turn
(B) Left turn
NOTE :
• Be sure
to return the turn-signal-light-switch to
center position after turning.
3. Hazard light switch
1. When you push the hazard-light-switch, the hazard
lights
flash along with the turn signal / hazard light
indicator on the instrument panel.
2. When you push the hazard-light-switch again, the
hazard lights turn off.
INSTRUMENT PANEL AND CONTROLS
INSTRUMENT PANEL, SWITCHES, AND HAND CONTROLS
