2. If
you feel less friction in folding the ROPS, follow
the following procedure.
a.
Remove the cotter pin.
b. Tighten the nut until you feel the right friction in
the movement.
c. Replace the cotter pin.
(1) Cotter pin (2) Nut
STARTING THE TRACTOR
[MANUAL TRANSMISSION
TYPE]
1. Adjust the operator's position.
•
Adjust the operator's seat.
(See Operator's seat on page
38)
(1) Travel adjust lever
(2) Suspension adjust handle
(A)
Pull
(B) To decrease tension
(C) To increase tension
• Adjust the seat belt.
(See Seat belt on page
38)
(1) Seat belt
NOTE :
• Adjust the
operator's seat and the
suspension to make sure that the controls
are comfortably at hand for the operator,
making sure that the operator maintains a
good posture and minimizes risks from
whole body vibration.
OPERATING THE TRACTOR STARTING THE TRACTOR [MANUAL TRANSMISSION TYPE]
60
L3301,L3901

Kubota L3901 Specifications

General

Engine Type	Diesel
Engine Horsepower	37.5 HP
3-Point Hitch	Category I
Weight	2, 623 lbs (Gear Drive), 2, 778 lbs (Hydrostatic)
Displacement	111.4 cu in
Cylinders	3
Displacement (cu in)	111.4
Hydraulic System Type	Open center
Width	55.1 inches
Transmission Type	Gear or HST
Fuel Capacity	11.1 gal
Gears	8 forward, 4 reverse (Gear)
Number of Gears	8 forward, 4 reverse
Fuel Tank Capacity	11.1 gal
Lift Capacity at 24"	1433 lbs
Height	91.7 inches
Tire Size (Front)	7-16
Tire Size (Rear)	11.2-24
Engine Model	D1803
