12. COOLING SYSTEM
12-13
MXU 300/250
THERMOSENSOR
THERMOSENSOR REMOVAL
Drain the coolant. (
page 12-7
)
Disconnect the thermosensor wire.
Remove the thermosensor from the
thermostat.
THERMOSENSOR INSPECTION
Suspend the thermosensor in a pan of water
over a burner and measure the resistance
through the sensor as the water heats up.
Temperature(℃)
50 80 100 120
Resistance(Ω)
154 52 27 16
THERMOSENSOR INSTALLATION
Apply 3-BOND No. 1212 sealant or
equivalent to the thermosensor threads and
install it into the thermostat housing.
Connect the thermosensor wire.
Fill the radiator with coolant. (
page
12-7)
Thermosensor Connectso
To Next Page
