KYMCO MXU 300 - ENGINE OIL;OIL FILTER; OIL PUMP

4. LUBRICATION SYSTEM
4-3
MXU 300/250
ENGINE OIL/OIL FILTER
OIL LEVEL AND OIL CHANGE
Refer to the “ENGINE OIL” section in the
chapter 3 to check the oil level and
replacement and oil filter cleaning.
OIL PUMP
REMOVAL
Remove the right crankcase cover and the
A.C. generator flywheel. (Refer to the “A.C.
GENERATOR/FLYWHEEL” section in the
chapter 16)
Remove the starter clutch gear. (Refer to the
“STARTER CLUTCH” section in the
chapter 18)
Remove the two bolts and oil separator
cover.
Pry off and remove the circlip from oil
driven sprocket.
Bolts
Oil Se
p
arator Cove
r
Circlip
