2M4/2M5/2M6/2M7
1-5-5
(3) Detaching and refitting the Right cover
Procedure
1. Remove the right upper cover and rear
upper cover R (see page 1-5-3).
2. Unhook the five hooks and then remove
the right cover.
Figure 1-5-7
Right cover
Hooks
Right cover
Hooks
Hook
