2M4/2M5/2M6/2M7-1
2-4-18
(13) Procedure for only replacing Developer unit
3 in 1 25/26 ppm model, 4 in 1 20/21, 25/26 ppm model
Procedure
1. Open the front cover.
2. Pull out the toner container.
* : Do not close the front cover.
3. Open the rear cover.
4. Remove the drum unit.
(see page P.2-4-6)
5. Remove the developer unit.
(see page P.2-4-7)
6. Install the new developer unit in the
machine.(see page P.2-4-12)
7. Install the toner container in the
machine.
* : Do not close the front cover.
8. Install the drum unit in the machine.
(see page P.2-4-13)
9. Close the rear cover.
10. Insert the power plug and turn the
power switch on.
11. Press the Menu key.
12. In the Menu. menu screen, press cursor
key to select System menu.Press the
OK key.
13. In the System menu screen, press cur-
sor key to select Adjust/ maint..Press
the OK key.
14. In the Adjust maintenance menu
screen, press cursor key to select Ser-
vice Setting.Press the OK key.
Figure 2-4-38
15. In the Service Setting menu screen,
press cursor key to select New Devel-
oper.Press the OK key.
* : If the Administrator ID entry display appears, use the numeric keys to enter the Administrator ID (4 dig-
its) and press OK key. The default setting is 2500 for the 25/26 ppm model, 2000 for the 20/21 ppm
model.
Menu
: System Menu
System Menu
: Adjust /maint.
Adjust /maint.
: Service Setting
Service Setting
: New developer
To Next Page
