2M4/2M5/2M6/2M7
2-4-7
(4) Detaching the developer unit
Procedure
1. Remove the developer unit by holding
both of its ends.
Figure 2-4-13
(5) Detaching the toner disposal box
Procedure
1. Take out the waste toner box by holding
it in the middle.
Figure 2-4-14
Developer unit
Toner disposal box
