2M4/2M5/2M6/2M7
1-4-5
1-4-2 Self-diagnostic function
(1) Self-diagnostic function
If a problem has occurred in the machine, you will be notified by the following display.
• The Attention indicator on the operation panel is lit or flashing.
• An error code appears in the display on the operation panel.
• KYOCERA Client Tool and Status Monitor will show the status of the machine.
If the Attention indicator is lit or flashing and an error code appears in the display on the operation panel,
check the KYOCERA Client Tool or Status Monitor.
3 in 1 25/26 ppm model, 4 in 1 20/21, 25/26 ppm model
Figure 1-4-3
3 in 1 20/21 ppm model
Figure 1-4-4
Error code: C-3100
This is displayed in repeating
two-digit segments (C- , 31, and 00).
To Next Page
