2M4/2M5/2M6/2M7
1-5-6
(4) Detaching and refitting the Left cover
Procedure
1. Remove the left upper cover and rear
upper cover L (see page 1-5-4).
2. Unhook the five hooks and then remove
the left cover.
Figure 1-5-8
Left cover
Left cover
Hooks
Hooks
Hook
