Configuration
7-20
48XX/49XXSHB0399
Code Name
Possible settings
Lenze Selection Info
C025¤ Input
selection:
Input
adjustment
2 -1- Terminals X1/1, X1/2
-2- Terminals X1/3, X1/4
-3- Terminal X1/6
-4- Terminal X1/8
-5- Armature voltage feedback
-10- Digital frequency input X5
-11- Digital frequency input X9
-12- Resolver X7
-13- Encoder output X8
Select the input which is to be adjusted
with C026, C027, C028 or C029 under
C025.
C026¤ Encoder
constant
for C025
0mV C007 = -5-, -6-, -9-, -20-:
Offset correction of the analog inputs
-9999 mV {1 mV} + 9999 mV
The encoder constants are not overwritten
when loading the factory setting.
0V C025 = -5-:
Offset correction of the armature voltage feedback
-100V {1V} +100V
1 C025 = -10-, -11-:
Encoder constant of the digital frequency inputs
-0- 8192 increments / revolution
-1- 4096 increments / revolution
-2- 2048 increments / revolution
-3- 1024 increments / revolution
-4- 512 increments / revolution
-5- 256 increments / revolution
3 C025 = -13-:
Encoder constant of the encoder output with resolver
feedback
-1- 256 increments / revolution
-2- 512 increments / revolution
-3- 1024 increments / revolution
-4- 2048 increments / revolution
C027 Gain factor
for C025
1.000 C007 = -5-, -6-, -9-, -20-:
Gain factor of the analog inputs
-2.500 {0.001} + 2.500
1.000 With C005 = -11-, -41-:
Gain factor of the tacho input X1/3, X1/4
0.010 {0.001} +9.999
1.010 C025 = -5-:
Gain factor fo the armature voltage feedback
0.100 {0.001} +9.999
0.1000 C025 = -10-, -11-:
Gain factor of the digital frequency input
-3.2767 {0.0001}+3.2767
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
1.000 C025 = -12-:
Gain factor of the resolvers
-32.767 {0.001} + 32.767
C028 Divisor for
C025
0.1000 C025 = -10-, -11-:
Divisor for the digital frequency inputs
0.0001 {0.0001} 3.2767
