Configuration
7-117
48XX/49XXSHB0399
7.8.6 Display functions
Code set
The factory setting is the display of the standard code set.
The extended code set is displayed when selecting C000 = -2-.
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C000¤ Code set 1 -0- (+ PW) Standard code set read only
-1- (+ PW) Standard code set
-2- (+ PW) Extendend code set
-9- For service only
-11- Code set automation module
Can only be changed via keypad!
If a password is defined under C094, a
change from -0- to -1- or -2- is only
possible after entering this password
(+ PW):
1. Change C000,
acknowledge with
SH + PRG .
2. Password setting with ▲ or ▼.
3. Accept with SH + PRG.
C094*¤ User
password
0 0 {1} 999 0 = No password protection
(see also C000)
Language
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C098 Language 0 -0- German
-1- English
-2- French
Actual value displays
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C051 n
act
speed -5000 rpm {1 rpm} +5000 rpm Display: actual speed
C052* Motor
voltage
0 V {1 V} 600 V Display: motor voltage V
A
C054 Motor
current
0.0 A 0.1 A} 100 A
100 A {1 A} 2000 A
Display: motor current I
A
C056 Torque
setpoint
-100.0 % M
max
{0.1 %} +100.0 % M
max
Display: Torque setpoint
Armature setting range: 100% M
max
correspond to 100% I
max
(C022, C023)
C060* Rotor
position
0...2047 Display: absolute rotor angle position,
standardized to 2048 incr./rev.
Incremental encoder feedback: display
only after zero track pulse.
C061* I¼tload 0.0 % {0.1 %} 105.0% Display: ”I¼tload”. Starting value when
switching on the mains is always 100 % !
C185 P
motor
-500.0 kW {0.1 kW} 500.0 kW Display: actual motor power
C186 M
motor
-999 Nm {1 Nm} 999 Nm Display: actual motor torque
C187 I
Fset
0.00 A {0.01 A} 50.0 A Display: actual field current setpoint
C188 I
Fact
0.00 A {0.01 A} 50.0 A Display: actual field current value
C189 f
mains
0.0 Hz {0.1 Hz} 100.0 Hz Display: actual mains frequency
