Accessories
13-3
48XX/49XXSHB0399
13.1.1 Mains fuses
Stop!
An additional cable protection is required when using fuses of the operating class
aR (partial characteristic) as phase fuses.
If the fuses of the operating class gR also protect the cable, the cable cross-
sections must be dimensioned according to the fuse. Otherwise, provide a
separate cable protection!
Type Max. perm. size of the phase fuse (F’1, F’2, F’3)
Mains voltage
$ 550V +0%
Fuse holder
Fuse type Operating class Order designation Order designation
4902 FF 32 A
(22 x 58)
gR EFSFF0320AYI EFH30006
4903 FF 40 A
(22 x 58)
gR EFSFF0400AYI EFH30006
4904 FF 80 A
(22 x 58)
gR EFSFF0800AYI EFH30006
4905 FF 200 A
(01.110)
aR EFSFF2000AYR EFH10003
4906 FF 250 A
(01.110)
aR EFSFF2500AYR EFH10003
4907 FF 350 A
(01.110)
aR EFSFF3500AYR EFH10003
4X08 FF 450 A
(01.110)
aR EFSFF4500AXP EFH10003
4X09 FF 700 A
(02.110)
aR EFSFF7000AYR EFH10003
TAB 1 Assignment of max. mains fuse size to the controller
Type
Recommended phase fuse size (F’1, F’2, F’3) when I
Amax
=I
Arated
of the
c
o
n
t
r
o
l
l
e
r
Fuse holder
con
t
ro
l
l
er
Mains voltage
$ 460V +0%
Fuse type Operating class Order designation Order designation
4902 FF 20 A
(14 x 51)
aR EFSFF0200AYH EFH10002
4903 FF 32 A
(14 x 51)
aR EFSFF0320AYH EFH10002
4904 FF 63 A
(22 x 58)
aR EFSFF0630AYI EFH30006
4905 FF 125 A
(00.80)
aR EFSFF1250AXL EFZ0003
4906 FF 200 A
(00.80)
aR EFSFF2000AXL EFZ0003
4907 FF 315 A
(00.80)
aR EFSFF3150AXL EFZ0003
4X08 FF 400 A
(01.110)
aR EFSFF4000AXR EFH10003
4X09 FF 550 A
(01.110)
aR EFSFF5500AXP EFH10003
TAB 2 Assignment of mains fuses to the controller when I
Amax
=I
Arated
and a mains voltage of $ 460V +0%
The controllers 4X11 to 4X13 are equipped with cell fuses (F1.1/F1.2, F2.1/F2.2,
F3.1/F3.2). Fuseholders are not necessary.
