Configuration
7-97
48XX/49XXSHB0399
Message with pulse inhibit
In the event of a failure the ignition pulses are only inhibited for the armature circuit,
the digital output IMP is set, and one of the freely assignable digital output is set
(if the function ”Message” is assigned to the output). The message is automatically
indicated under C065 and it is entered in the history buffer. The history buffer is
deleted when switching off the mains.
Message without pulse inhibit
In the event of a failure one of the freely assignable digital outputs is set (if the
function ”Message” is assigned to the output). The message is automatically
indicated under C065 and it is entered in the history buffer. The history buffer is
deleted when switching off the mains.
Name Lecom
No.
TRIP Warning Message
with IMP
Message
without
IMP
can be
switched
off
OC5 I¼toverload* 15 1 X - - -
OC6 I
2
¼toverload* 16 X X - - 1
OUE Mains overvoltage* 22 1 X - - -
LU1 Phase fault* 31 1 - X - X
LU Mains undervoltage 32 X - 1 - -
LF Underfrequency* 41 1 - X - -
OF Overfrequency* 42 1 - X - -
OH Heat sink overtemperature* 50 1 X - - -
CEO Communication fault with option 61 1 X - - X
U15 15V supply interfered* 70 1 X - - -
CCr System fault 71 X - - - -
PR Parameter fault 72 X - - - -
PR1 Parameter set 1 defective 72 X - - - -
PR2 Parameter set 2 defective 72 X - - - -
PR3 Parameter set 3 defective 72 X - - - -
PR4 Parameter set 4 defective 72 X - - - -
PER Program error 73 X - - - -
SP Wrong signal source polarity 80 1 X - - X
Sd1 Analog encoder defective 81 1 X - - X
Sd2 Resolver fault* 82 1 X - - X
Sd3 Encoder fault at X5* 83 1 X - - X
Sd4 Encoder fault at X9* 84 1 X - - X
Sd5 Set-value encoder at 4mA...20mA
defective
85 1 X - - X
EEr External error* 91 1 X X X -
dEr Motor blocked 93 1 X - - X
ACI armature circuit interrupted 94 1 X - - X
FCI Field circuit interrupted 96 1 X - - X
P03 Following error (tolerance exceeded) 153 X X X 1 X
P13 Angle overflow
(Detection not possible)
163 1 - - - X
CE9 Communication monitoring
Serial interface
69 X X X X 1
X = Selection possible - = Selection not possible 1 = Default setting
* Achnowledgement not possible during TRIP
