Lenze 4800 User Manual

Configuration
7-50
48XX/49XXSHB0399
7.3.4 Digital frequency output
DF output at the master
The following formula applied to the DF output:
Output frequency
=
C030
Rev.
Set speed.
Incr.
60
1
rpm
Hz
The max. output frequency is: f
max
 420kHz
(corresponds to 3080 rpm with encoder type 8192 incr./rev.)
DF output at the digital frequency cascade
The signal read in at X5 and evaluated with C026, C027 and C028 is output at
the DF output.
Output frequency
=
C030
Rev.
Set speed.
Incr.
60
1
rpm
Hz
The max. output frequency is: f
max
 420kHz
(corresponds to 3080 rpm with encoder type 8192 incr./rev.)
DF output at the digital frequency bar
The signal at X9 (hardware) is directly output with a gain at X8 (encoder output).
