Technical Data
3-3
48XX/49XXSHB0399
3.2 General data / application conditions
Field Values
Type of protection IP20 to DIN 40050, steel sheet housing
Permissible humidity Relative humidity 90%, no condensation
Temperature ranges
Storage
-25 C...+ 55 C
Tr a ns por t -25 C...+ 70 C
Influence of the installation height h $ 1000m : 100% rated armature current
h $ 2000m : 95% rated armature current
h $ 3000m : 90% rated armature current
h $ 4000m : 85% rated armature current
Degree of pollution VDE 0110, part 2, degree of pollution 2
Controllers must not be exposed to a corrosive or explosive
atmo-sphere.
Noise emission Requirements to EN 50081-2, IEC 22G
Limit-value class A (EN 55011; industrial premises) with RFI filter
Noise immunity Limit values maintained with RFI filter.
Requirements to EN 50082-2, IEC 22G
Requirements
Standard Severity
ESD EN 61000-4-2 3, i.e. 8kV air discharge
6 kV contact discharge
RF interference IEC 1000-4-3 3, i.e. 10 V/m
(enclosure)
Burst EN 61000-4-4 3/4, i.e. 2kV / 5kHz
Surge EN 61000-4-5 3, i.e. 1.2 / 50
m
s
1kV phase - phase
2kV phase - PE
