Lenze 4800 User Manual

Configuration
7-8
48XX/49XXSHB0399
Enable of additional acceleration and deceleration times
With terminal control, the inputs must be assigned according to the table below
to enable the additional acceleration and deceleration times. T
i
times can only be
activated in pairs.
input 2. input 3. input 4. input
T
ir1
,T
if1
1 0 0 0
T
ir2
,T
if2
0 1 0 0
T
ir3
,T
if3
1 1 0 0
T
ir4
,T
if4
0 0 1 0
T
ir5
,T
if5
1 0 1 0
T
ir6
,T
if6
0 1 1 0
T
ir7
,T
if7
1 1 1 0
T
ir8
,T
if8
0 0 0 1
T
ir9
,T
if9
1 0 0 1
T
ir10
,T
if10
0 1 0 1
T
ir11
,T
if11
1 1 0 1
T
ir12
,T
if12
0 0 1 1
T
ir13
,T
if13
1 0 1 1
T
ir14
,T
if14
0 1 1 1
T
ir15
,T
if15
1 1 1 1
The input with the lowest figure is the first input, the input with the next higher figure
is the second input, and so on (e. g. E4 = 1. input, E5 = 2. input).
C130 displays the momentarily active T
i
times.
With control via keypad or LECOM interfaces, C130 is used for the activation of
the T
i
times in pairs.
Code Name
Possible settings
Lenze Selection Info
C130*¤ Enable of
additional
T
i
times
0 -0- T
ir
(C012) / T
if
(C013) active
-1- T
ir1
/T
if1
active
...
-15- T
ir15
/T
if15
active
If the T
i
times are enabled via terminal,
C130 is for display only.
