Lenze 4800 User Manual

Configuration
7-120
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
[C005*] Configuration
11 Speed control with additional setpoint
-10- Armature voltage control
n
set
:analogatX1/8
n
add
:analogatX1/6
M
limit
: analog at X1/1, 1/2.
-11- Act. value encoder: tacho at X1/3,X1/4
n
set
:analogatX1/8
n
add
:analogatX1/6
M
limit
: analog at X1/1, X1/2
-12- Act. value encoder: resolver at X7
n
set
:analogatX1/8
n
add
:analogatX1/6
M
limit
: analog at X1/1, X1/2
-13- Act. value encoder: increment. encoder at X9
n
set
:analogatX1/8
n
add
:analogatX1/6
M
limit
: analog at X1/1, X1/2
If C005 = -10- or -40-, field control
override is not possible.
A change of the configuration changes the
control structure and the terminal
assignment and activates important
monitoring functions.
Change monitoring functions:
C119 / C120
Change terminal signals: C145 / C146.
Torque control with speed limitation and addi-
tional setpoint
-40- Armature voltage control
n
set
:analogatX1/8
n
add
:analogatX1/6
M
set
: analog at X1/1, 1/2.
-41- Act. value encoder: tacho at X1/3, X1/4
n
set
:analogatX1/8
n
add
:analogatX1/6
M
set
: analog at X1/1, 1/2.
-42- Act. value encoder: resolver at X7
n
set
:analogatX1/8
n
add
:analogatX1/6
M
set
: analog at X1/1, X1/2
-43- Act. value encoder: increment. encoder at X9
n
set
:analogatX1/8
n
add
:analogatX1/6
M
set
: analog at X1/1, X1/2
Dig. freq. of master with additional setpoint
-52- Act. value encoder: resolver at X7
n
set
:analogatX1/8
n
add
:analogatX1/6
M
limit
: analog at X1/1, X1/2
-53- Act. value encoder: increment. encoder at X5
n
set
:analogatX1/8
n
add
:analogatX1/6
M
limit
: analog at X1/1, X1/2
Digital frequency bus
-62- Act. value encoder: resolver at X7
n
set
: digital at X9
M
limit
: analog at X1/1, X1/2
-63- Act. value encoder: increment. encoder at X5
n
set
: digital at X9
M
limit
: analog at X1/1, X1/2
Digital frequency cascade
-72- Acutal value encoder: resolver at X7
n
set
: digital, X5
M
limit
: analog at X1/1, X1/2
C009*¤ Controller
address
1 1 {1} 99 Bus participant number for operation via
interface: Parameter 10 reserved for
broadcasting to groups of participants.
Can only be changed with C001 = -0-
and -1-.
