9300 Servo PLC
Preface and general information
1-4
L
ServoPLC EN 2.0
1.2.2 Module numbers
The system blocks of the 9300 Servo PLC carry the following module numbers:
Module number System block Notes
1 DIGITAL_IO Digital inputs/outputs
11 ANALOG1_IO Analog inputs/outputs 1
12 ANALOG2_IO Analog inputs/outputs 2
21 DF_IN_DigitalFrequency Digital frequency input
22 DF_OUT_DigitalFrequency Digital frequency output
31 CAN1_IO
System bus (CAN)
1
32 CAN2_IO
y
(
)
33 CAN3_IO
34 FIF_CAN1_IO
System bus (CAN), FIF module CAN-I/O
1
35 FIF_CAN2_IO
y
(
)
,
36 FIF_CAN3_IO
41 AIF1_IO_AutomationInterface
Automation interface
42 AIF2_IO_AutomationInterface
43 AIF3_IO_AutomationInterface
51 STATEBUS_IO State bus
101 CAN_Management System bus (CAN) management
1
102 CAN_Synchronisation System bus (CAN) synchronisation
1
121 DCTRL_DriveControl Unit control
131 MCTRL_MotorControl Motor control
141 FCODE_FreeCodes Free codes
151 SYSTEM_FLAGS System flags
161 AIF_IO_Management Automation interface management
1
SBs for system bus (CAN) are described in the “System bus (CAN) for Servo PLC & Drive PLC“ Manual.
The module number is part of an absolute SB address (see chapter 1.2.4). (^ 1-5)
