9300 Servo PLC
System blocks
2.12 MCTRL_MotorControl
2-45
L
ServoPLC EN 2.0
2.12.7 Speed controller
The speed controller is designed as an ideal PID - controller.
Parameter setting
By selecting a motor under C0086 the parameters are preset. Adaptations to your applications are
not always necessary.
• Use C0070 to set the proportional gain V
p
:
– Enter approx. 50% setpoint speed (100% = 16384 = n
max
).
– Increase C0070, until the drive becomes instable (observe motor noises).
– Reduce C0070 until the drives becomes stable again.
– Reduce C0070 to approx. half.
Code LCD
Possible settings
Info
o
Lenze Selection
o
C0070 Vp speed CTRL à V
pn
Speed controller
à depending on C0086
• Change of C0086 resets value to
the assigned default setting
0.0 {0.5} 255.0
• Use C0071 to adjust the readjustment time T
n
:
– Reduce C0071 until the drive becomes unstable (motor noise!).
– Increase C0071 until the drive becomes stable again.
– Increase C0071 to approx. twice the value.
Code LCD
Possible settings
Info
o
Lenze Selection
o
C0071 Tn speed CTRL à T
nn
Speed controller
à depending on C0086
• Change of C0086 resets value to
the assigned default setting
1.0 {0.5 ms} 600.0
>512 ms switched off
• Use C0072 to set the difference gain
d
:
– Increase C0072 during operation until the drive reaches an optimum control behaviour.
Code LCD
Possible settings
Info
o
Lenze Selection
o
C0072 Td speed CTRL 0.0 T
dn
Speed controller
0.0 {0.1 ms} 32.0
• Via MCTRL_nNAdapt_a V
p
can be changed using the PLC program.
V
p
= MCTRL_nNAdapt_a [% ]  C0070
Default:
MCTRL_nNAdapt_a = 100 % ð V
p
= 100 %  C0070 = C0070
Signal limit
The speed controller is operating within its limits as long as the drive outputs the max. torque.
• The drive cannot follow the speed setpoint.
• MCTRL_bMMax_b is set to TRUE.
