9300 Servo PLC
Appendix
3-38
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C2377 XCAN2 Mask AIF-CAN: XCAN2_OUT mask
0 {hex} FFFF
1 FFFF Mask for process output word 1
2 FFFF Mask for process output word 2
3 FFFF Mask for process output word 3
4 FFFF Mask for process output word 4
C2378 XCAN3 Mask AIF-CAN: XCAN3_OUT mask
0 {hex} FFFF
1 FFFF Mask for process output word 1
2 FFFF Mask for process output word 2
3 FFFF Mask for process output word 3
4 FFFF Mask for process output word 4
C2382 XCAN Conf. CE AIF-CAN: Monitoring configuration
0Off
1 Controller inhibit
2QSP
1 0 XCAN1_IN (no telegram received)
2 0 CAN2_IN (no telegram received)
3 0 XCAN3_IN (no telegram received)
4 0 Bus off
5 0 Life Guarding Event
C2500 Temporary codes (see cha pter 3.4.1)
0 {1} 65535
1 0 %MW 0
... ... ...
255 0 %MW 254
C2501 Temporary codes (see cha pter 3.4.1)
0 {1} 65535
1 0 %MW 255
... ... ...
255 0 %MW 509
3.4.1 Temporary codes
Codes C2500 and C2501 are temporary codes, i.e. their data
• do not use any EEPROM memory space.
• cannot be saved in the parameter set of the unit using C0003 = 1.
• will be lost after mains disconnection or power failure.
• are linked with the PLC flag area.
• Temporary codes should be used for parameters which are accessed during a switch-on
cycle of the PLC.
• It is also possible to directly access the flag are of the PLC (e.g via HMI) without having to
create a variable.
