2.14 SYSTEM_FLAGS
2-68
L
ServoPLC EN 2.0
2.14 SYSTEM_FLAGS
(Module number 151)
System flags are global variables which are permanently integrated into the run-time system. They
include functions that facilitate programming.
The following system flags are included in the 9300 Servo PLC/Drive PLC:
VariableName DataType Address Note
SYSTEM_bClock01Hz %IX151.0.0 0.1 Hz System clock
SYSTEM_bClock1Hz %IX151.0.8 1.0 Hz System clock
SYSTEM_bClock10Hz %IX151.1.0 10 Hz System clock
SYSTEM_bClock0100Hz %IX151.1.8 100 Hz System clock
SYSTEM_bTogCycleTask %IX151.2.0 Toggle marker cyclic task
SYSTEM_b1LoopCyclicTask %IX151.2.8 First loop cyclic task
SYSTEM_b1LoopTask2
B
o
o
l
%IX151.3.0 First loop task ID2
SYSTEM_b1LoopTask3
Bool
%IX151.3.8 First loop task ID3
SYSTEM_b1LoopTask4 %IX151.4.0 First loop task ID4
SYSTEM_b1LoopTask5 %IX151.4.8 First loop task ID5
SYSTEM_b1LoopTask6 %IX151.5.0 First loop task ID6
SYSTEM_b1LoopTask7 %IX151.5.8 First loop task ID7
SYSTEM_b1LoopTask8 %IX151.6.0 First loop task ID8
SYSTEM_b1LoopTask9 %IX151.6.8 First loop task ID9
SYSTEM_nTaskInterval
I
n
t
e
g
e
r
%IW151.7 Interval of current task
SYSTEM_nTaskID
In
t
eger
%IW151.8 ID-number of current task
Tip!
The system variables are not generated in simulation mode.
SYSTEM_bClockxHz
These system flags output a fixed clock pulse with an equal pulse/pause ratio.
• The flag is toggled in real time.
• When you use this system flag, take care with the frequency used for polling the flag (aliasing
effect). You should use at least twice the toggle frequency.
Example:
You would like to use the system flag
SYSTEM_bClock100Hz as a clock for a counter.
• The pulse/pause ratio is 5 msec/5 msec.
• To avoid an aliasing effect, the counter must always be polled with an INTERVAL-TASK
