9300 Servo PLC
System blocks
2.12 MCTRL_MotorControl
2-47
L
ServoPLC EN 2.0
2.12.10 Phase controller
The phase controller is needed to ensure phase-synchronous running and drift-free standstill.
Parameter setting
1. Assign
MCTRL_nPosSet_a
to a signal source that provides the phase-angle difference
between the set and actual phase-angles.
2. At
MCTRL_nPosLim_a
enter a value > 0.
3. Set
MCTRL_bPosOn_b
=TRUE.
4. Use C0254 to set the phase controller gain > 0.
Before you set C0254, select a P-gain for the n-controller as high as possible under C0070.
(^ 2-45)
During operation increase C0254, until the drive shows the desired control behaviour.
Code LCD
Possible settings
Info
o
Lenze Selection
o
C0254 Vp angle CTRL 0.4000 V
p
Phase controller
0.0000 {0.0001} 3.9999
Phase controller influence
The output of the phase controller is added to the speed setpoint.
If the actual phase is lagging, the drive is accelerated.
If the actual phase is leading, the drive is decelerated, until the desired phase synchronisation
is achieved.
The influence of the phase controller consists of:
Phase difference multiplied by the P-gain V
p
(C0254).
Additional influence of an analog signal at
MCTRL_nPAdapt_a
.
(V
p
= C0254
MCTRL_nPAdapt_a
/ 16384)
Limitation of the phase controller output to ±
MCTRL_nPosLim_a
.
Limiting of the phase-angle controller output
This limits the maximum catch-up speed of the drive in the event of large phase differences.
