Product Overview
output ports and connectors:
Î
Î
Î
Î
Î
Î
Î
Î
Î
Î
Î
Î
HDMI-3D-OPT-TX210A
HDMI-3D-OPT-TX210RAK
SW4-OPT-TX240RAK
1
HDCP status LED LED gives feedback about the HDCP
status of the video output signal. See
details in the HDCP LED section.
2
USB connector USB interface for LDC connection,
function.
3
DisplayPort input DisplayPort connector for DisplayPort
4
HDMI input
video and audio.
4
9
re
61 2
q w
4
9
re
61 2
q w
4
8 97
re
5
3 61 2
q w
5
DVI-D input
6
Audio1 input
analog audio input signal.
7
Video Select
button
Button for switching between video
sources. See the details in the
Select Button section.
8
Autoselect status
LED
LED gives feedback about the status of
Autoselect feature. See the details in the
Autoselect LED section.
9
Audio2 status
LED
LED gives feedback about actual
connection status of Audio2 input port
(on the rear side of device).
q
USB LED LED gives feedback about the status of
USB operations (LDC control, firmware
the details in the USB LED section.
w
Reset button Reset button reboots the extender. This
is the same as disconnecting the device
from the power source and reconnecting
it again.
e
Audio Select
button
Button for switching between audio
sources. See the details in the Audio
Select Button section.
r
Show Me button Special functions are available with this
button (switch to bootload mode, enable
DHCP, restore factory default settings,
condition launching in Event Manager).
For the details about special functions
see the Special Functions - Transmitter
section.
INFO: Operation of the audio and video status LEDs can be found in
the and the Audio Input LEDs sections.
