 HDMI-3D-OPT series – User's Manual 64

Command format: GET●
Response format: pr●
n

Legend:

n
 Audio input port number
Example:
˃ GET /MEDIA/AUDIO/XP.DestinationConnectionList
˂ pr /MEDIA/AUDIO/XP.DestinationConnectionList=I1
Explanation: I1 input port is connected to the output port.
Switching Audio Input
Command format: CALL●
n

m

Response format: mO●
Example:
˃ CALL /MEDIA/AUDIO/XP:switch(I2:O1)
˂ mO /MEDIA/AUDIO/XP:switch
Explanation: I2 port is connected to O1 port.

Command format: GET●
Response format: pr●
n

The response shows the settings of each output one by one.
Legend:
 
n
 
Letter Explanation
1
st
letter
E: Autoselect is enabled.
D: Autoselect is disabled.
2
nd
letter
F: First
P: Priority detect mode: always the highest priority active audio input will be selected.
L: Last detect mode: always the last attached input is switched to the output automatically.
S: Static mode: the audio input follows the selected video if the video signal contains
embedded audio.
Example:
˃ GET /MEDIA/AUDIO/XP.DestinationPortAutoselect
˂ pr /MEDIA/AUDIO/XP.DestinationPortAutoselect=EL
Explanation:
EL: the Autoselect is Enabled on output, selected mode is Last detect.
INFO: For more information about the Autoselect feature see The Autoselect Feature section.
Change the Autoselect Mode
Command format: CALL●
n

n

Response format: mO●
Legend: See at previous section.
Example1:
˃ CALL /MEDIA/AUDIO/XP:setDestinationPortAutoselect(O1:EPM)
˂ mO /MEDIA/AUDIO/XP:setDestinationPortAutoselect
Explanation1
(P), and the port will be disconnected if a higher priority port becomes active (M).
Example2:
˃ CALL /MEDIA/AUDIO/XP:setDestinationPortAutoselect(O1:D)
˂ mO /MEDIA/AUDIO/XP:setDestinationPortAutoselect
Explanation2              
unchanged. Since the outputs are linked, the change will affect local and link out.
INFO: For more information about the Autoselect feature see The Autoselect Feature section.




