11. Appendix HDMI-3D-OPT series – User's Manual 93
to a device, the followings will be overwritten:
DP input port
DVI-D input port
Analog audio input ports
Crosspoint settings
Audio autoselect settings, Mute ports, Lock ports, Switch ports
Optical output port
Test pattern mode, clock source, and type
HDCP mode, HDMI mode
RS-232 mode, Control protocol, CI port number, Port name
Local output port
Test pattern mode, clock source, and type
Serial port
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity
Port name and CI (Command Injection) port number
Static IP address, Network mask, Gateway address
Event manager: settings of all Events (E1-E20)
section.
OM1 OM2 OM3 OM4
1080p@60Hz 24 bpp 600 m 1200 m
1080p@60Hz 36 bpp 400 m 800 m 1300 m
4096x2048@30Hz 24 bpp Not supported 700 m 1100 m
