11. Appendix HDMI-3D-OPT series – User's Manual 92
Transmitter
Parameter
I1 (DisplayPort)
Audio I1 (DisplayPort)
HDCP Enabled
HDCP mode Enabled
Autoselect * Disabled
Autoselect mode * Priority detect
Autoselect video priority *
Test pattern mode Off
Test pattern resolution 480p
Test pattern Bar
Signal type Auto
HDCP mode Auto
Laser enable On
Analog audio input port properties
0.00 dB
Balance 0 (center)
Gain 0.00 dB
Autoselect * Disabled
Autoselect mode * Priority detect
Autoselect video priority *
IP address 192.168.0.100
Subnet mask
Static gateway 192.168.0.1
DHCP Disabled
10001
Parameter
RS-232 settings
Control protocol
Operation mode Pass-through
Command injection port nr. 8001
Direction Input
Output level High
Receiver
Parameter
Optical input port properties
HDCP Enabled
HDMI output port properties
Signal type Auto
HDCP mode Auto
Always on
Test pattern mode Off
Test pattern resolution 480p
Test pattern Bar
Analog audio output port properties
Balance 0 (center)
Bass 0.00 dB
Treble 0.00 dB
Phase invert Disabled
RS-232 settings
Control protocol
Operation mode Pass-through
For the procedure of reloading factory default values in LDC software see the System section, or using the
function buttons see in the Reset to Factory Default Settings section for the transmitter and the Reset to
Factory Default Settings section for the receiver.
