HDMI-3D-OPT series – User's Manual 48
Set the Gateway Address
Description: Gateway address can be set as follows.
Example
Legend
the static IP gateway address that is stored in the device even if DHCP is enabled. In that case, the latest
valid gateway address (for static IP) is stored.
Apply Network Settings
Description: Apply the network settings and restart the network interface.
Example
Command {ip_apply}
Response (IP_APPLY)CrLf
{ip_apply}
(IP_APPLY)
Set Level and Direction for Each Pins
Description
and about the interface in the section.
Example
{gpio1=O;H}
(GPIO1=O;H)
Legend:
Parameter <dir> Description
I Input
O Output
Parameter <level> Description
L Low
H High
T Toggle
Explanation: GPIO pin 1 is set to output with high level.
GPIO pin number 1...8
The direction of the communication, it can be input or output.
The level of the pin, it can be low or high.
