LTH Electronics MXD70 Series User Manual

Registers
Modbus RS485 Interface
Operating Guide
- 17 -
Registers
Modbus RS485 Registers
Base instrument configuration
Note. The availability of some of the registers depends upon the configuration of the unit.
Register
#
Access
Rule
Channel Name Data
Format
Description of
Attribute
Semantics of Values
Instrument Information
2000 Get Company INT Company Name
2001 Get
Get
Instrument Type INT Type Of Instrument 1406 = Panel Mount
1407 = Surface Mount
2002 Get Serial Number LONG Instrument Serial
Number
2004 Get Software Version FLOAT The software version of
the base instrument
0.00 to 99.99
Instrument Configuration
2010 Get/Set Language INT Instrument Language
Settings
1000 = English
1001 = French
1002 = Spanish
1003 = Italian
2011 Get/Set System Clock Hour INT System Clock – Hour
element ( HH:MM )
0 to 23 Hours
2012 Get/Set System Clock Minute INT System Clock – Minute
element ( HH:MM )
0 to 59 Minutes
2013 Get/Set System Clock Week Day INT System Clock – Day of
the week
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
7 = Sunday
2014 Get/Set System Clock Date INT System Clock – Date
Element ( DD:MM:YYYY )
1 to 31 Date
2015 Get/Set System Clock Month INT System Clock – Month
Element ( DD:MM:YYYY )
1 to 12 Month
2016 Get/Set System Clock Century INT System Clock – Century
Element ( DD:MM:YYYY )
0 to 3000
2017 Get/Set Daylight Savings INT Daylight Savings Status 1076 = Yes
1077 = No
2018 Get/Set Daylight Savings Start
Occurrence
INT The occurrence on
which Daylight Savings
should Start (i.e. last
Sunday in March)
1 = First
2 = Second
3 = Third
4 = Fourth
5 = Last
