LTH Electronics MXD70 Series User Manual

Registers
- 26 -
Modbus RS485 Interface
Operating Guide
Registers
Setpoint / Relay Status
Register
#
Access
Rule
Channel Name Data
Format
Description of
Attribute
Semantics of Values
Setpoint Status
3100 Get Setpoint 1 Setpoint State INT Current State Of
Setpoint
0 = Setpoint Not
Active
3150 Setpoint 2
3200 Setpoint 3 1 = Setpoint Active
3250 Setpoint 4 2 = Setpoint Initial
Charge Active
3300 Setpoint 5
3350 Setpoint 6 3 = Setpoint Dose
Alarm
3101 Get Setpoint 1 Setpoint
Cleaning
Position
INT Current Cleaning
Position When setpoint
source set to Cleaning
0 = Not Cleaning
3151 Setpoint 2 1 = Clean Delay
3201 Setpoint 3 2 = Cleaning
3251 Setpoint 4 3 = Recovery
3301 Setpoint 5
3351 Setpoint 6
3102 Get Setpoint 1 Setpoint
Cleaning Type
INT Current Type Of
cleaning When setpoint
source set to Cleaning
0 = Regular Cleaning
3152 Setpoint 2 2 = Digital Input
Cleaning
3202 Setpoint 3
3252 Setpoint 4 3 = Manual Cleaning
3302 Setpoint 5
3352 Setpoint 6
3103 Get Setpoint 1 Setpoint Pulse
Proportion
Percentage
INT Setpoint Pulse
Proportion Percentage
0 to 100%
3153 Setpoint 2
3203 Setpoint 3
3253 Setpoint 4
3303 Setpoint 5
3353 Setpoint 6
3104 Get Setpoint 1 Setpoint
Cleaning Hours
INT Time remaining for the
Setpoint Cleaning
Interval, (Hours)
0 to 12
3154 Setpoint 2
3204 Setpoint 3
3254 Setpoint 4
3304 Setpoint 5
3354 Setpoint 6
3105 Get Setpoint 1 Setpoint
Cleaning
Minutes
INT Time remaining for the
Setpoint Cleaning
Interval, (Minutes)
0 to 59
3155 Setpoint 2
3205 Setpoint 3
3255 Setpoint 4
3305 Setpoint 5
3355 Setpoint 6
3106 Get Setpoint 1 Setpoint
Cleaning
Seconds
INT Time remaining for the
Setpoint Cleaning
Interval, (Seconds)
0 to 59
3156 Setpoint 2
3206 Setpoint 3
3256 Setpoint 4
3306 Setpoint 5
3356 Setpoint 6
