LTH Electronics MXD70 Series User Manual

Registers
- 64 -
Modbus RS485 Interface
Operating Guide
Registers
Setpoint Configuration
Register
#
Access
Rule
Setpoint Name Data
Format
Description of
Attribute
Semantics of Values
Setpoint Configuration
8000 Get/Set Setpoint 1 Channel INT Assigned Input Channel 1159 = Disabled
8080 Setpoint 2 1160 = Channel 1
8160 Setpoint 3 1161 = Channel 2
8240 Setpoint 4 1162 = Channel 3
8320 Setpoint 5 1163 = Unit Alarm
8410 Setpoint 6 1164 = Calculation 1
1165 = Calculation 2
8001 Get/Set Setpoint 1 Source INT Input Source 1166 = Sensor
8081 Setpoint 2 1167 = Temperature
8161 Setpoint 3 1168 = Pressure
8241 Setpoint 4 1169 = Alarm
8321 Setpoint 5 1170 = Cleaning
8411 Setpoint 6
8002 Get/Set Setpoint 1 Range* INT Range
*(Only available when
the range of Assigned
Input Channel is set to
Auto)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
8082 Setpoint 2
8162 Setpoint 3
8242 Setpoint 4
8322 Setpoint 5
8412 Setpoint 6
8003 Get/Set Setpoint 1 Trigger INT Trigger 1173 = High
8083 Setpoint 2 1174 = Low
8163 Setpoint 3 1175 = Band
8243 Setpoint 4 1176 = Latch High
8323 Setpoint 5 1177 = Latch Low
8413 Setpoint 6 1178 = USP*
1179 = USP Pre-Trigger*
*(only available for
Conductivity)
8004 Get/Set Setpoint 1 Usp Pre-
Trigger*
FLOAT USP Pre-Trigger Value
*(Only available for
Conductivity)
0.000µS/cm to 9.999µS/cm
8084 Setpoint 2
8164 Setpoint 3
8244 Setpoint 4
8324 Setpoint 5
8414 Setpoint 6
8006 Get/Set Setpoint 1 High Value* FLOAT Trigger High Value
*(Not available when
Trigger is set to Low)
Value depends on input
channel assigned to
8086 Setpoint 2
8166 Setpoint 3
8246 Setpoint 4
8326 Setpoint 5
8416 Setpoint 6
