Registers
Modbus RS485 Interface
Operating Guide
- 71 -
Registers
Digital Input Configuration
Register
#
Access
Rule
Current
Output
Name Data
Format
Description of
Attribute
Semantics of Values
Digital Input Configuration
9500 Get/Set Digital IP 1 Channel INT Assigned Input Channel 1159 = Disabled
9520 Digital IP 2 1160 = Channel 1
9540 Digital IP 3 1161 = Channel 2
9560 Digital IP 4 1162 = Channel 3
9580 Digital IP 5 1163 = Whole Unit
9600 Digital IP 6
9620 Digital IP 7
9640 Digital IP 8
9501 Get/Set Digital IP 1 Function INT Function 1280 = Offline
9521 Digital IP 2 1281 = Cleaning
9541 Digital IP 3 1282 = Range Changing
9561 Digital IP 4 1283 = Switch Setup
9581 Digital IP 5 1284 = Interlock
9601 Digital IP 6 1285 = Flow Switch Input
9621 Digital IP 7 1286 = Tank Level Switch
9641 Digital IP 8 1287 = Calibration
1288 = Initial Charge
1289 = CIP
9502 Get/Set Digital IP 1 Store* INT Switch Setup Store
*(Only available when
Function is set to Switch
Setup)
1300 = Store A
9522 Digital IP 2 1301 = Store B
9542 Digital IP 3
9562 Digital IP 4
9582 Digital IP 5
9602 Digital IP 6
9622 Digital IP 7
9642 Digital IP 8
9503 Get/Set Digital IP 1 Polarity INT Digital Input Operating
Polarity
1298 = Normally Open
9523 Digital IP 2 1299 = Normally Closed
9543 Digital IP 3
9563 Digital IP 4
9583 Digital IP 5
9603 Digital IP 6
9623 Digital IP 7
9643 Digital IP 8
9504 Get/Set Digital IP 1 Range* INT Digital Input Switched
Range
*(Only available when
Function is set to Range
Changing)
Refer To Tables 2 and 3
and Sensor Configuration
Manuals
9524 Digital IP 2
9544 Digital IP 3
9564 Digital IP 4
9584 Digital IP 5
9604 Digital IP 6
9624 Digital IP 7
9644 Digital IP 8
