Registers
Modbus RS485 Interface
Operating Guide
- 73 -
Registers
Display Configuration
Register
#
Access
Rule
Channel Name Data
Format
Description of
Attribute
Semantics of Values
Front Screen Configuration
9700 Get/Set Channel 1 Channel Shown INT Channel Shown 1402 = Channel 1 Yes
1405 = Channel 1 No
9850 Channel 2 1403 = Channel 2 Yes
1405 = Channel 2 No
10000 Channel 3 1404 = Channel 3 Yes
1405 = Channel 3 No
9701 Get/Set Channel 1 Character 1 INT Label 1
st
Character Refer To Table 1 (excluding
symbols)
9851 Channel 2
10001 Channel 3
9702 Get/Set Channel 1 Character 2 INT Label 2
nd
Character
9852 Channel 2
10002 Channel 3
9703 Get/Set Channel 1 Character 3 INT Label 3
rd
Character
9853 Channel 2
10003 Channel 3
9704 Get/Set Channel 1 Character 4 INT Label 4
th
Character
9854 Channel 2
10004 Channel 3
9705 Get/Set Channel 1 Character 5 INT Label 5
th
Character
9855 Channel 2
10005 Channel 3
9706 Get/Set Channel 1 Character 6 INT Label 6
th
Character
9856 Channel 2
10006 Channel 3
9707 Get/Set Channel 1 Character 7 INT Label 7
th
Character
9857 Channel 2
10007 Channel 3
9708 Get Channel 1 Character 8 INT Label 8
th
Character
9858 Channel 2
10008 Channel 3
Auxiliary mA Inout Front Screen Secondary Reading Configuration
9720 Get/Set Channel 1 Secondary
reading 1
INT Secondary reading 1 Refer To Table 6
9870 Channel 2
10020 Channel 3
9721 Get/Set Channel 1 Secondary
reading 2
INT Secondary reading 2
9871 Channel 2
10021 Channel 3
To Next Page
