9-7
Chapter 9 LUBRICATION SYSTEM
2.
Lubrication System - Disa
ssemble, Inspect and Assemble
2.1
Oil Pump and Safety V
alv
e - Disas
semble and Inspect
Oil Pump and Safety V
alve - Disassemble and Inspect
1
2
3
4
5
6
7
8
9
Crack, flaw
Crack, flaw
Gear defect, wear
Gear defect, wear
Spring settling, break, wear
Wear
Wear
Wear
Disassembling Sequence
1
Safety valve
2
Pump cover
3
Drive gear
4
Oil pump gear
5
Dr
iven gea
r
6
Nut
7
Spindle
8
Idler gear
9
Pump case
211
213
