Chapter 10 COOLING SYSTEM
2.9
Air Cooler W
ater Pump
- Disas
semble and Inspect
Air Cooler W
ater Pump - Disassemble and Inspect
5
6
7
9
8
10
11
4
3

2
PT
A
W spec
Corrosion, crack, flaw
Replace
Replace
Wear
, flaw
Corrosion, flaw
Rotation
Rotation
Disassembling Sequence
1
Water pump pulley
2
Snap ring
3
Cover
4
Impeller
5
Snap ring
6
Water pu
mp shaft
7
Ball bearing
8
Spacer
9
Ball bearing
10
Unit seal
11
Water pump case (Approx 15 kg [33 lb])
242
244
