10-5
Chapter 10 COOLING SYSTEM
1.3
Sea W
ater Pump and Water
Pipe - Rem
ove and Insp
ect
Sea W
ater Pump and Water Pipe - Remove and Inspect
1
1
2
3
4
5
6
7
8
9
9
9
9
9
9
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Heat exchanger
Heat
exchanger
TK spec
MPTK spec
MTK spec
MPT
AW spec
TK, MTK, MPTK,
MPT
A
W spec
Rear plate
Air cooler
MPTK spec
MTK spec
Replace
Removing Sequence
1
Water pipe
2
Coupling
3
Water pipe
4
Ori
fice
5
Connector
6
Water pip
e
7
Plate
8
Sea water pump
9
Water pipe
228
