12-3
Chapter 12 AIR START SYSTEM
Chapter 12 AIR ST
ART SYSTEM
1.
Air S
t
art System -
Remove and Inspect
1.1
Magnetic V
alve - Remove and Inspe
ct
Magnetic V
alve - Remove and Inspect
1
2
3
6
7
5
4
Air direct starting spec
Removing Sequence
1
Air pipe
2
Flexible pipe
3
Stay
4
Air strainer
5
Magnetic valve
6
St
ay
7
St
ay
276
