Chapter 2 SERVICE DATA
Main
bearing
Thickness at
center
Standard
3.500
[0.1378]
3.467 to 3.480
[0.1365 to 0.1370]
3.425
[0.1348]
Under
size
0.25
3.625
[0.1427]
3.592 to 3.605
[0.1414 to 0.1419]
3.550
[0.1398]
0.50
3.750
[0.1476]
3.717 to 3.730
[0.1463 to 0.1469]
3.675
[0.1447]
0.75
3.875
[0.1526]
3.842 to 3.855
[0.1513 to 0.1518]
3.800
[0.1496]
1.00
4.000
[0.1575]
3.967 to 3.980
[0.1562 to 0.1567]
3.925
[0.1545]
Trust
plate
Thickness
Standard
5.00
[0.1969]
4.78 to 4.85
[0.1882 to 0.1909]
4.71
[0.1854]
Over
size
0.25
5.25
[0.2067]
5.03 to 5.10
[0.1980 to 0.2008]
4.96
[0.1953]
0.50
5.50
[0.2165]
5.28 to 5.35
[0.2079 to 0.2106]
5.21
[0.2051]
0.75
5.75
[0.2264]
5.53 to 5.60
[0.2177 to 0.2189]
5.46
[0.2150]
Crankcase
Distortion of top surface 0.1 [0.004] or less
0.2
[0.008]
Inside diameter of main bearing bore
ø147
[5.79]
147.000 to 147.025
[5.7874 to 5.7884]
147.035
[5.7888]
Depth of counterbore in crankcase
14.00 to 14.05
[0.5512 to 0.5531]
Height from journal center to top face
(Reference value)
549.45 to 549.55
[21.6318 to 21.6358]
Unit: mm [in.]
Item
Nominal
value
Standard value Limit value Remarks
