Motorola Solutions AP-6511 Access Point System Reference Guide
13-38
The General field describes the following:
The Specification field displays the following:
Name Displays the name of the interface.
Interface MAC
Address
Displays the MAC address of the interface.
IP Address IP address of the interface.
IP Address Type Lists the IP address type of the interface
Hardware Type Displays the hardware type.
Index Displays the unique numerical identifier supporting the interface.
Access VLAN Displays the interface the VLAN has access to.
Access Setting Displays the mode of the VLAN—Access or Trunk.
Administrative
Status
Displays whether the interface is currently UP or DOWN.
Media Type Displays the physical connection type of the interface.
Medium types are:
Copper - Used on RJ-45 Ethernet ports
Optical - Used on fibre optic gigabit Ethernet ports
Protocol Displays the name of the routing protocol adopted by the interface.
MTU Displays the maximum transmission unit (MTU) setting configured on the
interface. The MTU value represents the largest packet size that can be sent
over a link. 10/100 Ethernet ports have a maximum setting of 1500.
Mode The mode can be either:
Access – This Ethernet interface accepts packets only from the native VLANs.
Trunk – This Ethernet interface allows packets from a given list of VLANs that
you can add to the trunk.
Metric Displays the metric value associated with the route through this interface.
Maximum Speed Displays the maximum speed at which the interface transmits or receives
data.
Admin. Speed Displays the speed setting used when using the administrative interface.
Operator Speed Displays the current speed of the data transmitted and received over the
interface.
Admin. Duplex
Setting
Displays the administrator’s duplex setting.
Current Duplex
Setting
Displays the interface as either half duplex, full duplex, or unknown.
