9 Visualization
Maschinenfabrik Reinhausen GmbH 2020128 6385142/08 ENETOS
®
ED
Baud rate
You can use this parameter to set the serial interface's baud rate. You can
select the following options:
▪ 9600 baud
▪ 19200 baud
▪ 38400 baud
▪ 57600 baud
▪ 115200 baud
ASDU address
You can use this parameter to set the address of the ASDU.
Number of data bits
You can use this parameter to set the number of databits.
Parity
You can use this parameter to set the parity. You can select the following
options:
▪ None
▪ Even
▪ Odd
Number of stop bits
You can use this parameter to set the number of stop bits.
DFC compatibility
You can use this parameter to set how the device is to use the DFC bit (Data
Flow Control) in the control field. You can select the following options:
Option Description
Standard The device sets the DFC bit in each response to a com-
mand. The device thus indicates that the master may not
send any further commands. The master must react to
the ACD bit (Access Demand) and retrieve the response
to the command e.g. via a request for data of class 1
from the slave queue.
Alternative The device sets the DFC bit in a response if a second
command is received without the master having previ-
ously sent a request for data of class 1.
Table29: DFC compatibility
