MR ETOS ED User Manual

6 Mounting
Maschinenfabrik Reinhausen GmbH 2020 716385142/08 EN ETOS
®
ED
Cable Assembly Cable type Conductor
cross-section
Conductor
material
Max. length
Voltage measurement UI1, UI3, UI5-4 Shielded 2.5mm² Copper -
Current measurement UI1, UI3, UI5-4 Unshielded 4mm² Copper -
Signal inputs DIO28-15,
DIO42-20
Shielded 1.5mm
2
Copper 400m (<25Ω/km)
Signal outputs* DIO28-15,
DIO42-20
Shielded 1.5mm
2
Copper -
Signal inputs AIO2, AIO4,
AIO8
Shielded 1mm
2
Copper 400m (<25Ω/km)
Signal outputs AIO2, AIO4,
AIO8
Shielded 1mm
2
Copper -
RS232, SUB-D CPUI, CPUII Shielded 0.25mm
2
- 25m
RS485; SUB-D CPUI, CPUII Shielded 0.25mm
2
- 140m
CAN bus CPUI Shielded 0.75mm² - 2,000 m (total
CAN bus)
Ethernet RJ45 CPUI Min. CAT5,
shielded S/FTP
For
ETOS®EDXL
Angle plug rec-
ommended
- - 100m
Ethernet FO MC2-2, SW3-3 Duplex LC
Multimode, OM3,
1310nm
- - 2000m
Table13: Recommendation for connection cables
*) Observe line capacitance, see note above.
6.4.2 Information about connecting serial interfaces RS232 and RS485
NOTICE
Damage to the device!
Using the wrong data cable may damage the device.
► Only use data cables which comply with the description below.
