12 Removal
Maschinenfabrik Reinhausen GmbH 2020370 6385142/08 ENETOS
®
ED
To remove the control cabinet, proceed as follows:
► Remove the vertical drive shaft and protective tube between the bevel
gear and control cabinet.
Figure261: Removing the protective tube and horizontal drive shaft
▪ WARNING! Serious injuries and damage to the control cabinet due to
falling load. Attach the lifting gear such that the cable angle is always less
than 45° in relation to the vertical.
