Connect your router
NOTE: If both your Internet service provider (ISP) and modem support a speed
of 10 Gbps, the router’s Internet connection also functions at 10 Gbps.
Otherwise, the Internet connection functions at the maximum speed that is
supported by both your ISP and your modem. (1 Gbps is a common speed.)
Figure 3. Connect the router to a modem
To connect your router to a modem:
1.
Unplug your modem’s power, leaving the modem connected to the wall jack for
your Internet service.
2.
If your modem uses a battery backup, remove the battery.
3.
Plug in and turn on your modem.
4.
If your modem uses a battery backup, put the battery back in.
5.
Connect your modem to the Internet port of your router with the Ethernet cable that
came with your router.
User Manual18Overview and Setup
Whole Home Quad-Band Mesh WiFi 7 System
